Introduction
The EFLECH and INDEX programs have no limitations. You should not use
this programs after December 2010.
Index at level 5.1.1 has successfully passed
a set of 17 test examples consisting of
- 3 cubic examples: fluorite, magnetite, Y2O3
- 2 tetragonal examples: cassiterite, zircon
- 3 hexagonal examples: corundum, quartz, zincite
- 2 orthorhombic examples: anhydrite, PbSO4
- 3 monoclinic examples: epidote, gypsum, muscovite
- 4 triclinic examples: K2Cr2O7, kyanite,
plagioclase, wollastonite
In all cases, the default values for ignore= were in usage. The
whole set takes 19h 15min on a 3.0GHz Phenom II PC (4 threads in use).
Licence Conditions
- Use the programs at your own risk.
- Using the programs is not allowed after December 2010.
- For any questions, mailto
support@bgmn.de
- A full licence is included into the packages.
- If results achieved with EFLECH/INDEX are to be published, please see
here for a paper appropriate for citation.
Installation instructions
Download the appropriate program files and the
data files ('bgmndata.zip'). Create a directory 'rietveld' in the root of a
volume (e.g. c:). Then unzip the program files and the data files into this
directory. Append this directory to the path. Set the environment variable
EFLECH to the program directory:
EFLECH=c:\rietveld
Now you are ready to run EFLECH/INDEX.
It is recommended to create separate subdirectories for each analytical task
(e.g. c:\rietveld\k2cr2o7) and to run all programs from these
subdirectories. These subdirs should contain the control file
(*.sav), the measuring data file
(*.val, *.rd, *.raw)
and the instrumental function file
(*.geq/*.ger).
Actual Release is 5.1.3
Download area
- Programs for Windows:
relatedwin32.zip (327819 bytes)
- Programs for Linux (compiled on Fedora 11 as distributed):
relatedlinux.tar.gz
(360042 bytes)
- Additional, you need the BGMN demo packet to
be installed. Especially:
- GEOMET/MAKEGEQ for generation of peak model parameters
- OUTPUT for generating a peak list
- SHOW (PLOT1) for EFLECH result output
- Of course, you must download the BGMN data
packet too!
- Example K2Cr2O7
The Linux example includes the binary *.geq file for Intel
processors. It may not be used on other UNIX systems.
