We want to demonstrate applicability of automatic (variable) divergence slit

Therefore, we use the widely known Round Robin sample PbSO4 as described in
J. Appl. Cryst. 25 (1992) pp. 589-610.

We have learned: irradiated sample length should be at maximum 10mm. Maximum divergence angle should be much less than take-off angle of X-rays from tube anode. The latter angle usually is 6°.

We have collected all results into a table. Table colums are marked as follows:

  1. column RR: Range of results from ibid.
  2. column RR-BGMN: Data as distributed, re-evaluated using BGMN.
  3. column F1: Own measurement of RR sample PbSO4 using fixed divergence slit 1mm.
  4. column V5: Own measurement of RR sample PbSO4 using variable divergence slit, 5mm irradiated sample length.
  5. column V10: Own measurement of RR sample PbSO4 using variable divergence slit, 10mm irradiated sample length.
  6. column X: Single crystal data as described ibid.
Value RR RR-BGMN F1 V5 V10 X
Rexp 1.5%-7.0% 5.36% 6.16% 4.96% 3.70% -
Rwp 8.2%-20% 7.84% 8.36% 7.91% 6.48% -
a/Å 8.4764-8.4859 8.4760(2) 8.4789(6) 8.4786(5) 8.4786(4) 8.482(2)
b/Å 5.3962-5.4024 5.3957(2) 5.3991(4) 5.3989(3) 5.3986(3) 5.398(2)
c/Å 6.9568-6.9650 6.9563(2) 6.9589(5) 6.9588(4) 6.9588(4) 6.959(2)
Pb: x 0.1875-0.1883 0.18790(7) 0.1880(1) 0.1881(1) 0.18790(7) 0.1879(1)
Pb: z 0.1669-0.1683 0.16714(1) 0.1672(2) 0.1674(2) 0.1671(2) 0.1667(1)
Pb: B/Å2 0.9-2.39 1.52(2) 1.44(2) 1.30(2) 1.63(2) 1.48
S: x 0.0621-0.0673 0.0631(4) 0.0636(6) 0.0632(5) 0.0636(4) 0.0633(6)
S: z 0.6799-0.6860 0.6849(5) 0.6878(7) 0.6852(7) 0.6851(5) 0.6842(7)
S: B/Å2 0.29-1.37 0.83(7) 1.0(1) 0.7(1) 1.04(7) 0.74
O1: x 0.902-0.924 0.906(1) 0.907(2) 0.909(1) 0.907(1) 0.908(2)
O1: z 0.585-0.601 0.597(1) 0.598(2) 0.599(2) 0.598(2) 0.596(3)
O1: B/Å2 0.50-4.2 1.2(2) 0.8(2) 0.8(2) 1.0(2) 1.87
O2: x 0.177-0.200 0.191(2) 0.192(2) 0.191(2) 0.191(2) 0.194(2)
O2: z 0.523-0.548 0.547(2) 0.546(2) 0.543(2) 0.545(2) 0.543(2)
O2: B/Å2 0.1-5.8 1.4(2) 1.6(3) 0.6(2) 1.4(2) 1.76
O3: x 0.071-0.080 0.0786(6) 0.0808(8) 0.0810(8) 0.0790(6) 0.082(1)
O3: y 0.018-0.041 0.026(1) 0.024(2) 0.026(2) 0.026(1) 0.026(2)
O3: z 0.806-0.819 0.811(1) 0.807(2) 0.805(2) 0.807(1) 0.809(2)
O3: B/Å2 0.8-4.6 0.9(2) 0.7(2) 0.7(2) 0.8(2) 1.34

Remarks:

Obviously, results of variable divergence measurements are a little less accurate compared to those of fixed divergence measurements (especially Debye-Waller factors B). But, in principle, automatic (variable) divergence slits are usable for Rietveld refinements.
